Radiocrafts offers high performance, high quality and cost-effective standard RF modules for use in a variety of wireless short-range applications.
About Radiocrafts
Radiocrafts design and manufacture modules based on standardized HW platforms with silicon from leading suppliers. They add firmware to make the module a user-friendly device supporting a wide range of wireless technologies.
Supported Technologies
RIIM™ by Radiocrafts
An IIoT Wireless IP Mesh Network in a module developed for you to easily create your own industrial grade access network with direct IP connectivity.
Technology Features:
- Frequency Range (MHz): 868, 915
- Regions: EU, US
- Range, LOS (m): 5,000 to 20,000
- Network Type: Mesh
- Sensitivity (dBm): -110/-111
- Data Rate (kbps): 50
- Output Power (dBm): 14, 27
MIOTY
MIOTY is an LPWAN protocol designed to have the best-in-class reliability and scalability of all available LPWAN technologies today to support massive industrial IoT deployments.
Technology Features:
- Frequency Range (MHz): 868, 915
- Regions: EU, US
- Range, LOS (m): 20,000
- Network Type: Star
- Sensitivity (dBm): -129
- Data Rate (kbps): 2.38
- Output Power (dBm): 14
RIIoT™ by Radiocrafts
RIIoT is an RF system designed to meet the sensor and actuator connectivity requirements for the Industrial IoT.
Technology Features:
- Frequency Range (MHz): 868, 915
- Regions: EU, US
- Range, LOS (m): 3,000 to 8,000
- Network Type: Star
- Sensitivity (dBm): -110/-120
- Data Rate (kbps): 5/50
- Output Power (dBm): 14
M-Bus Wireless
Easy to Use wireless standard protocol for communication to and between water, gas, heat, electricity meters, and data concentrators.
Technology Features:
- Frequency Range (MHz): 169, 433, 868, 915
- Regions: EU, Russia, India, Brazil, US, Australia
- Range, LOS (m): 500 to 8,000
- Network Type: Star, single hop repeaters
- Sensitivity (dBm): -101 to -119
- Data Rate (kbps): 2.4 to 100
- Output Power (dBm): 10, 27, 30
Tinymesh™
Tinymesh™ is a powerful and efficient wireless mesh network infrastructure solution with a ready to implement cloud service.
Technology Features:
- Frequency Range (MHz): 169 to 2483
- Regions: Worldwide
- Range, LOS (m): 300 to 10,000
- Network Type: Mesh
- Sensitivity (dBm): -105 to -118
- Data Rate (kbps): 0.3 to 100
- Output Power (dBm): 10 to 27
RC232
RC232 is a point-to-point or point to multi-point protocol, proven in the industry. An Easy to Use cable replacement and networking protocol.
Technology Features:
- Frequency Range (MHz): 169 to 2483
- Regions: Worldwide
- Range, LOS (m): 300 to 4,000
- Network Type: Star, multi-hop repeaters
- Sensitivity (dBm): -105 to -110
- Data Rate (kbps): 1.2 to 100
- Output Power (dBm): -1 to 27
KNX
The international wireless standard protocol for home- and building automation by the KNX Association.
Technology Features:
- Frequency Range (MHz): 433, 868
- Regions: EU (worldwide)
- Range, LOS (m): 500
- Network Type: Star, multi-hop repeaters
- Sensitivity (dBm): -101
- Data Rate (kbps): 16/32
- Output Power (dBm): 10
Sigfox
Discover IoT solutions connecting your devices to the cloud using ultra narrowband radio for very long range and countrywide coverage.
Technology Features:
- Frequency Range (MHz): 868, 915
- Regions: EU, US, Australia, LatAM
- Range, LOS (m): 10,000
- Network Type: Star (Base Station)
- Sensitivity (dBm): -126 (downlink)
- Data Rate (kbps): 0.1/0.6
- Output Power (dBm): 14, 24
ZNM
ZNM is the most popular low-cost, low-power wireless mesh networking standard for home-, building- and industrial- automation.
Technology Features:
- Frequency Range (MHz): 2400 to 2483
- Regions: Worldwide
- Range, LOS (m): 500 to 2,500
- Network Type: Mesh
- Sensitivity (dBm): -99
- Data Rate (kbps): 250
- Output Power (dBm): 3, 20
Do you have a project in mind?
Need some guidance on your next project? Or just simply want to know where to get started incorporating M2M/IoT technology into your business?
Use our contact form to submit your questions and one of our team of M2M/IoT experts will get back to you with more information.
